Flyaway Antenna

Newstar is the reliable flyaway antenna manufacturer in China. Our flyaway antennas are made of carbon fiber and aluminum reflector materials. The flyaway antennas are available in C-band, X-band, Ku-band and Ka-band, including 0.75m, 1m, 1.2m, 1.8m and 2.4m diameter.

Request a Quote

1.8m C,Ku Band Aluminum Manual Flyaway Antenna

Factory Price, OEM, ODM

Antenna diameter: 1.8m
Antenna type: offset
Material: Aluminum
Net weight: 85Kg
gross weight: 162Kg
Antenna package: Aviation package case/Wooden case
Antenna travel range AZ EL Pol: 0°~360° 0°～90° ±90°
Antenna drive mode: Manual
Panel quantity: 4 pieces

Request a Quote

Description

Main functional characteristics

Conform with Intelsat, Eutelsat Requirements;

Carbon fiber reflector, high strength, light weight;

Good cross-polarization, low sidelobe, high efficiency;

Convenient and quick dismounting & adjustment;

Without tools, assembly & pointing star within 15 minutes;

Adopt the "Three-proof " measures, modern production process, meet various field work environments;

4 Pieces panel, narrow&light in the collection.

RF Specifications

Model		NS-FM-180
Operating Frequency GHz		Ku band		C band
	Rx	10.95～12.75		3.625～4.2
	Tx	13.75～14.5		5.85～6.425
Antenna gain dBi	Rx	≥45.6dBi		35.8dBi
	Tx	≥46.7dBi		39.5dBi
Polarization		Linear		Linear
XPD, dB(on axis ) -1dB		≥35		≥35
		≥30		≥30
Port isolation	Tx-Rx	≥85dB
VSWR		1.25:1
Tx Power capacity, KW		1kw/port				5kw/port
-3dB Beamwidth, Mid-Band		0.92°	0.78°			2.87°		1.93°
Feed Interface		WR-75	WR-75		CPR-229G		CPR-159G/137G
Feed Insertion Loss,dB		0.35	0.35		0.15		0.17
First Sidelobe,dB 90% Peaks under Following Envelop ,dBi		-14 29-25㏒θ（1°≤θ＜20°）				-14 29-25㏒θ（1°≤θ＜20°）

Mechanical Specifications

Antenna diameter	1.8m
Antenna type	offset
Material	Aluminum
Antenna weight	Net weight: 85Kg; gross weight: 162Kg
Antenna package	Aviation package case/Wooden case
Antenna travel range AZ EL Pol	0°~360° 0°～90° ±90°
Antenna drive mode	Manual
Panel quantity	4 pieces

Environment Specifications

Working wind speed	13m/s(45km/h)(add counterweight)
Working temperature	-40℃～60℃
Relative Humidity	100%
Solar radiation	1135Kcal/h/m²
