4.5m High Speed Rotary Platform Uplink Antenna

Factory Price, OEM, ODM
  1. Meets or exceeds CCIR 580 and INTELSAT requirements;

  2. Meets INTELSAT, ASIASAT, CHINASAT network access requirement;

  3. Ring-focus designed;

  4. High gain, low sidelobe, High G/T rate;

  5. Hot-dip zinc processed Antenna mount, with strong corrosion-resistant ability;

  6. Linear or circular polarization optional;

  7. Reasonable structure and easy operation.


4.5m high speed rotary uplink  antenna characteristics

With high reliability, the entire antenna system is very stable;
High security, the antenna material, accessories, electrical components, etc. are in accordance with world-class standards. In the design of both, the antenna itself or personal safety have adequate protection.
Antenna has good wind resistance, anti-corrosion, and other abilities.
Wide rotating range: azimuth can be 360° rotation, elevation up and down 90°rotation. Motorized polarization device, the antenna can quickly and automatically execute the command under the control system; Reasonable structure, beautiful appearance, and long service life; The entire antenna technology adopts the top domestic technology, it greatly increases antenna's mechanical accuracy and reduces antenna's maintenance cycle; High accuracy antenna panel; C/Ku/Ka-band compatible, linear pol, circular pol and linear /circular pol convertible all can be configured; High gain, low sidelobe, high polarization discrimination.
1.8m Ka band VSAT antenna
1.8m Ka band VSAT antenna
1.8m Ka band VSAT antenna
4.5m high-speed rotary antenna view 1
4.5m high-speed rotary antenna view 2
4.5m high-speed rotary antenna view 3

4.5m high speed rotary uplink antenna specifications

Antenna control system
Tracking accuracy Better than one-tenth receiving 3dB beamwidth
Angle sensor Standard with absolute, single-turn 16-bit optical encoder, accuracy ±0.0220° Optional absolute, single-turn 18-bit optical encoder, accuracy±0.0220°
Display resolution 0.01°(standard);   0.001°(optional)
Power input requirements Power supply:220(1±10﹪)V,50(1±5﹪)Hz;
power consumption:300VA
Power supply:380(1±10﹪)V,50(1±5﹪)Hz;
power consumption:3KVA
Tracking interface Standard(0-10V)analog voltage input interface,connector:
Remote communication interface Remote network interface: standardRJ-45
System wiring (1) Motor Cable:RVVP4*1.5mm² (2) Code plate limit switch cable:RVSP2*6*0.5mm²
Safety (1) Soft/hard limit provide protection for the safe rotation of the antenna (2) Inverter has short circuit, overload, lack of phase protection and other functions
Working environment  Antenna controller operating temperature:-20°C~ + 50°C; Cable operating temperature (standard):-10°C~ + 50°C; Cable operating temperature (optional):-30°C~ + 50°C;Low temperature cable
